HIGH-SPEED TUBULAR CENTRIFUGE ideal for Food, Biotechnology & pharmaceutical Industries


  Tubular Centrifuge is a high speed solid bowl type machine for continuous separation of two immiscible liquids with density difference. This centrifuge is also used to separate small quantity of impurities from liquids...


  • Pharmaceutical Industries
  • Chemical & Food Industries
  • Food Industries
  • Edible Oil Industries
  • Printing Ink
  • Bacteria Cell Separation
  • Fuel Oil Purification
  • Paint Industries
  • Gum Clarification
  • Biodiesel Plants
  • Beverage Industry
  • Biomass Separation
  • Blood Fractionation


High-Speed Tubular Centrifuge
HSTC-142-G

Technical Data
Separation factor (xg) 15760
Inner diameter - bowl 142 mm
Bowl length 820 mm
Bowl volume 10 Liter
Rotational speed 14000 rpm
Production capacity 1.5 m3/h
Motor power 3000 watt
Dimensions (L×W×H) 910×620×1770 mm
Weight 900 kg
High-Speed Tubular Centrifuge
HSTC-105-Q, 105-QF, 105-G

Technical Data
Separation factor (xg) 15000
Inner diameter - bowl 105 mm
Bowl length 730 mm
Bowl volume 6 Liter
Rotational speed 16000 rpm
Production capacity 1.2 m3/h
Motor power 3000 watt
Dimensions (L×W×H)
800×450×1620 mm
780×460×1640 mm (105-G)
Weight 550 kg, 750kg (105-G)


*HSTC-105-Q = Round-Enclosure Liquid-Liquid Seperation
HSTC-105-QF= Round-Enclosure Liquid-Solid Seperation,
HSTC- 105-G =Square-Enclosure for cleaning



High-Speed Tubular Centrifuge
HSTC-76

Technical Data
Separation factor (xg) 17000
Inner diameter - bowl 76 mm
Bowl length 430 mm
Bowl volume 2 Liter
Rotational speed 20000 rpm
Production capacity 0.2 m3/h
Motor power 1500 watt
Dimensions (L×W×H) 650×380×1150 mm
Weight 180 kg
RB-10 Peristaltic Pump Series
Technical Data
model RB-10
Rotational speed 200 - 700 r/min
Capacity 4-10 L/min
Pressure 1.5 Kg
Motor Power 220 watt
Power Supply 380 V
*Silicone Tube φ10x16.5
Dimensions (L×W×H)
460×200×210 mm
Weight 12 kg



   APPLICATION

  === Biotechnology & Pharmaceutical Industries ===
as liquid users, from processing to wastewater treatment are required mechanical solid-liquid separation. Clarify whether it is liquid, two liquid separation, solid mixture classification or classification of liquid-solid mixtures can be carried out in a continuous decanter centrifuge, its on-site environmental and healthy conditions, isolates are guaranteed. Decanters are gradually used in Trandional medicine purification, bio-pharmaceutical, fermentation, cell culture medium...

  === Food production & Processing Industries ===
hygienic requirements are priority. Decanters can provide one of the aspects of the closed solid-liquid separation in line with international food, 3A sanitary standards of the processing environment, wetted parts are made ​​in high quality stainless steel (Food-Grade)and polished and ground handling, separation of solids non-stick parts of the surface. In order to prevent the rot in the system solid fouling, specially equipped CIP system enables automatic drum interior thoroughly cleaned...

  === Chemical Processing Industries ===
Large capacity, high separation factor, optimized spiral structure, good corrosion resistance of the body, such as the closure of the separation characteristics of the environment in line with the chemical production process requires solid-liquid separation. In the course of a chemical reaction, the chemical can be quickly separated using a centrifuge, to reduce the time of the reverse reaction or side reaction, and effectively increase the yield of the reaction. The areas of application are: chemical intermediates generated during the production, recovery of the catalyst extraction, the extraction process of the resin solids, non-fossil fuels such as biodiesel and ethanol production processes...



Tubular Centrifuge is a high speed solid bowl type machine for continuous separation of two immiscible liquids with density difference. This centrifuge is also used to separate small quantity of impurities from liquids...



  • Pharmaceutical Industries
  • Chemical & Food Industries
  • Food Industries
  • Edible Oil Industries
  • Printing Ink
  • Bacteria Cell Separation
  • Fuel Oil Purification
  • Paint Industries
  • Gum Clarification
  • Biodiesel Plants
  • Beverage Industry
  • Biomass Separation
  • Blood Fractionation
